CD4011B Quad 2-Input NAND Gate IC TI Friendly DIP-14 Pack of 3

Description

Product Overview

The CD4011B is a quad 2‑input NAND gate IC from Texas Instruments, packaged in a DIP‑14 layout that fits easily on standard breadboards. Each gate delivers a typical propagation delay of 60 ns at 10 V, buffered inputs and outputs, and a maximum input current of just 1 µA at 18 V. Designed to meet JEDEC Tentative Standard No. 13B, it offers consistent performance across a wide temperature range and supports 5‑V, 10‑V, and 15‑V rating options.

Usage

This IC is ideal for digital logic circuits, signal conditioning, and timing applications in both industrial equipment and hobbyist projects. Its low power consumption and robust noise margins make it suitable for automotive control units, consumer electronics, and educational labs where reliable NAND functionality is required.

Why Choose Us

We source genuine TI components, ensuring each CD4011B undergoes 100 % testing for quiescent current and performance consistency. Our packaging includes a pack of three units, providing extra inventory for development cycles and reducing reorder time. Customer support includes technical datasheets and design assistance.

Key Features

• Fast 60 ns typical propagation delay for quick signal processing
• Buffered inputs and outputs reduce loading effects in circuits
• Low input current (1 µA max) helps conserve power in battery‑operated devices
• Broad voltage compatibility (5‑15 V) fits many design requirements
• Dedicated technical support and genuine TI warranty for peace of mind

FAQ

What is the maximum supply voltage?

The CD4011B operates safely up to 15 V, with typical specifications provided for 5 V, 10 V, and 15 V supply levels.

Can this IC be used in high‑temperature environments?

Yes, it is rated for the full JEDEC temperature range, making it suitable for industrial and automotive applications.

Is the pack of three ICs suitable for prototyping?

Absolutely. Having three units allows you to test multiple circuit variations without immediate reordering.

Do you provide the datasheet?

Yes, a complete TI datasheet is available for download on our product page.

What is the noise margin?

Noise margin is 1 V at 5 V supply, 2 V at 10 V, and 2.5 V at 15 V, ensuring reliable logic levels.
